15CrMoG seamless steel pipe; used in the manufacture of various low
and medium pressure boilers, superheated steam pipes, boiling water
pipes, water wall pipes and superheated steam pipes for locomotive
boilers, large smoke pipes, small smoke pipes and arch brick pipes,
etc.
15CrMoG seamless steel pipe chemical composition%
Carbon: 0.12~0.18, Silicon: 0.15~0.40, Manganese: 0.40~0.740,
Phosphorus: ≤0.025, Sulfur: ≤0.025, Chromium: 0.80~1.20,
Molybdenum: 0.45~0.60
The principle of purifying hydrogen in 15CrMoG seamless steel pipe
is that when the hydrogen to be purified is passed into one side of
15CrMoG seamless steel pipe at 300-500 ° C, hydrogen is adsorbed on
the wall of 15CrMoG alloy tube, due to the lack of 4d electron
layer of palladium Two electrons, which can form unstable chemical
bonds with hydrogen (this reaction between palladium and hydrogen
is reversible), under the action of palladium, hydrogen is ionized
into protons with a radius of 1.5×1015m, and the lattice constant
of palladium It is 3.88×10-10m (at 20°C), so it can pass through
the 15CrMoG seamless steel pipe, and under the action of palladium,
the protons combine with electrons to form hydrogen molecules
again, and escape from the other side of the 15CrMoG seamless steel
pipe. On the surface of 15CrMoG seamless steel pipe, undissociated
gas is impermeable, so 15CrMoG seamless steel pipe can be used to
obtain high-purity hydrogen.
Specifications and appearance quality of high-pressure boiler
tubes: GB5310-2008 "Seamless Steel Tubes for High-Pressure Boilers"
hot-rolled tubes have an outer diameter of 22-530mm and a wall
thickness of 20-70mm. Cold-drawn (cold-rolled) tubes have an outer
diameter of 10-108mm and a wall thickness of 2.0-13.0mm.
15CrMoG seamless steel pipe is a steel widely used in the electric
power industry, and it has high thermal strength when used at
500°C-550°C. When the use temperature is higher than 550°C, its
thermal performance will be significantly reduced. 15CrMoG seamless
steel pipe is mainly used for high and medium pressure pipelines
with a steam parameter of 510°C, steam guide pipes, and heater
pipes with a pipe wall temperature of 550°C.
15CrMoG seamless steel pipe belongs to chrome-molybdenum alloy
heat-resistant steel pipe, the implementation standard is GB
5310-2008 seamless steel pipe standard for high-pressure boilers;
it is applied to steam pipes, headers and wall temperature of high-
and medium-pressure boilers with steam parameters of power plant
boilers at 510 °C Superheater tubes, forgings and elastic
components at 540°C.
Zhengde hot-rolled seamless steel pipe is a long strip of steel
with a hollow section and no joints around it. The steel pipe has a
hollow cross-section and is widely used as a pipeline for
transporting fluids, such as pipelines for transporting oil,
natural gas, gas, water and certain solid materials. Compared with
solid steel such as round steel, seamless steel pipe is lighter in
weight when the bending and torsional strength is the same. It is
an economical section steel and is widely used in the manufacture
of structural parts and mechanical parts, such as oil drill pipes
and automobile transmission shafts. , bicycle racks and steel
scaffolding used in building construction, etc. The use of seamless
steel pipes to manufacture ring parts can improve the utilization
rate of materials, simplify the manufacturing process, save
materials and processing hours, such as rolling bearing rings, jack
sets, etc., which have been widely used in steel pipes. Hot-rolled
seamless steel pipe is also an indispensable material for various
conventional weapons. Gun barrels, barrels, etc. must be made of
steel pipes.
thick Φ | 3 | 3.5 | 4 | 4.5 | 5 | 5.5 | 6 | 6.5 | 7 | 8 | 8.5 | 9 | 10 | 12 |
32 | 2.146 | 2.46 | 2.762 | 3.052 | 3.329 | 3.594 | 3.847 | 4.088 | | | | | | |
38 | 2.589 | 2.978 | 3.354 | 3.718 | 4.069 | 4.408 | 4.735 | 5.049 | | | | | | |
42 | 2.885 | 3.323 | 3.749 | 4.162 | 4.562 | 4.951 | 5.327 | 5.691 | | | | | | |
45 | 3.107 | 3.582 | 4.044 | 4.495 | 4.932 | 5.358 | 5.771 | 6.172 | | | | | | |
50 | 3.477 | 4.014 | 4.538 | 5.049 | 5.549 | 6.036 | 6.511 | 6.973 | 7.423 | 8.286 | 8.699 | | | |
54 | 3.773 | 4.359 | 4.932 | 5.493 | 6.042 | 6.578 | 7.103 | 7.614 | 8.114 | 9.075 | 9.538 | | | |
57 | 3.995 | 4.618 | 5.228 | 5.826 | 6.412 | 6.985 | 7.546 | 8.095 | 8.632 | 9.667 | 10.167 | | | |
60 | 4.217 | 4.877 | 5.524 | 6.159 | 6.782 | 7.392 | 7.99 | 8.576 | 9.149 | 10.259 | 10.796 | | | |
63.5 | 4.476 | 5.179 | 5.869 | 6.548 | 7.214 | 7.867 | 8.508 | 9.137 | 9.754 | 10.95 | 11.529 | | | |
68 | 4.809 | 5.567 | 6.313 | 7.047 | 7.768 | 8.477 | 9.174 | 9.858 | 10.53 | 11.838 | 12.473 | | | |
70 | 4.957 | 5.74 | 6.511 | 7.269 | 8.015 | 8.749 | 9.47 | 10.179 | 10.876 | 12.232 | 12.892 | 13.539 | 14.797 | 17.164 |
73 | 5.179 | 5.999 | 6.807 | 7.602 | 8.385 | 9.156 | 9.914 | 10.66 | 11.394 | 12.824 | 13.521 | 14.205 | 15.537 | 18.052 |
76 | 5.401 | 6.258 | 7.103 | 7.935 | 8.755 | 9.563 | 10.358 | 11.141 | 11.912 | 13.416 | 14.15 | 14.871 | 16.277 | 18.94 |
89 | 6.363 | 7.38 | 8.385 | 9.378 | 10.358 | 11.326 | 12.281 | 13.225 | 14.156 | 15.981 | 16.875 | 17.756 | 19.483 | 22.787 |
108 | 7.768 | 9.02 | 10.259 | 11.486 | 12.701 | 13.903 | 15.093 | 16.27 | 17.436 | 19.729 | 20.858 | 21.973 | 24.168 | 28.41 |
133 | | 11.178 | 12.725 | 14.261 | 15.783 | 17.294 | 18.792 | 20.278 | 21.751 | 24.662 | 26.098 | 27.522 | 30.334 | 35.809 |
159 | | 13.422 | 15.29 | 17.146 | 18.989 | 20.821 | 22.639 | 24.446 | 26.24 | 29.791 | 31.548 | 33.293 | 36.746 | 43.503 |
219 | | 18.601 | 21.209 | 23.805 | 26.388 | 28.959 | 31.517 | 34.064 | 36.598 | 41.629 | 44.126 | 46.61 | 51.543 | 61.259 |
273 | | 23.262 | 26.536 | 29.797 | 33.046 | 36.283 | 39.508 | 42.72 | 45.92 | 52.283 | 55.445 | 58.596 | 64.86 | 77.24 |
325 | | 27.75 | 31.665 | 35.568 | 39.458 | 43.337 | 47.202 | 51.056 | 54.897 | 62.542 | 66.346 | 70.137 | 77.684 | 92.629 |
355 | | | | 38.897 | 43.158 | 47.406 | 51.641 | 55.865 | 60.076 | 68.46 | 72.634 | 76.796 | 85.082 | 101.507 |
377 | | | | 41.339 | 45.871 | 50.39 | 54.897 | 59.391 | 63.873 | 72.801 | 77.246 | 81.679 | 90.508 | 108.018 |
426 | | | | 46.777 | 51.913 | 57.036 | 62.147 | 67.246 | 72.332 | 82.468 | 87.518 | 92.555 | 102.592 | 122.519 |
450 | | | | | | | | 71.093 | 76.475 | 87.203 | 92.549 | 97.882 | 108.511 | 129.621 |
480 | | | | | | | | 75.902 | 81.654 | 93.122 | 98.837 | 104.54 | 115.909 | 138.499 |
530 | | | | | | | | 83.917 | 90.286 | 102.987 | 109.319 | 115.638 | 128.24 | 153.296 |
630 | | | | | | | | 99.947 | 107.549 | 122.716 | 130.281 | 137.833 | 152.902 | 182.89 |
Our Advantages

Three-roll pipe mill
The seamless steel pipe produced by the three-roll mill for
hot-rolling seamless steel pipe has high precision. Because of the
cross-rolling with the mandrel, the rolling action is repeated many
times in one pass, which greatly improves the accuracy of the wall
thickness and is not easy to produce. Defects such as scratches,
ears, and green lines; the flexibility in production is large, and
the pass size can be changed with the help of the clutch of the
roll.
Adequate inventory
Standing inventory of carbon seamless tubes, seamless
special-shaped tubes, alloy seamless tubes, precision tubes.
Various types of seamless steel pipes with a specification of
5-426*0.5-60mm and a length of 2-16m. The cold-rolled precision
bright tubes produced by our factory have smooth appearance,
uniform wall thickness, no oxide layer, and high precision. The
inner hole of the steel pipe can be divided into round type, spline
type, plum blossom type, etc. It is widely used in automobiles,
motorcycles, electric power, petrochemicals, ships, aerospace,
bearings, pneumatic components, oil cylinders, boiler equipment,
medical equipment, fitness equipment and other industries.
Attention to detail
No matter how to choose the hot-rolled seamless steel pipe, its
quality cannot be ignored. It must be noted that there should be no
defects on the surface, such as small cracks or scars, etc., and
that the thickness of the pipe wall is the same to ensure
uniformity. The physical comparison is still very important. Only
after the basic comparison of the physical objects is done, can the
steel pipes that meet the needs be selected. The processing
technology of each seamless steel pipe is different, which will
also affect its application field. Now it is generally processed by
cold drawing and hot rolling, and the processing effect of the two
and the application of steel pipes will also have certain
differences.
Applicable scene
Hot-rolled seamless pipes specifically include low and medium
pressure boiler steel pipes, high-pressure boiler steel pipes,
seamless steel pipes for ships, petroleum cracking steel pipes,
seamless steel pipes for high-pressure fertilizer equipment, oil
jacket steel pipes, pipeline steel pipes, hollow sucker rods, and
ordinary fluid steel pipes. , structural seamless steel pipes and
imported alloy steel pipes, etc., with rich varieties and complete
specifications, widely used in petroleum, chemical, electric power,
boilers, ships, machinery and other industries, and have been sold
all over the world.
Quality first: production and inspection in strict accordance with
production standards;
Price advantage: discounts based on real market prices;
Transaction security: There will be no loss of customer funds;
After-sales guarantee: the customer's problem is our problem;
Long-term cooperation: quality assurance, price advantage, sincere
service can last for a long time.Detailed Photos



Packaging & Shipping

Company Profile
Shandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel
coils, cold-rolled steel coils, galvanized steel coils,
color-coated steel coils, section steel, steel pipes, steel wires,
metal mesh, stainless steel, aluminum, copper and other metal
products integrated large enterprises. Five production and sales
bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan
and Tai'an, with more than 100 production lines, 4 nationally
recognized laboratories, 2 technical engineering centers, and 5
enterprise technology centers. Products are exported to more than
50 countries and regions such as North America, South America,
Europe, Africa, Oceania, Middle East, and Southeast Asia.

Certifications
