10mm-3000mm Width Pre Painted Galvanized Steel Sheet And Coils With Slit Edge

Ask Lasest Price
Certification :	ISO, RoHS, IBR
Brand Name :	Zhengde Metal
Price :	negotiable
Payment Terms :	Western Union, MoneyGram, T/T
Supply Ability :	30000 Tons/Month

Add to Cart

Product Details
Company Profile

10mm-3000mm Width Pre Painted Galvanized Steel Sheet And Coils With Slit Edge

Customized High Quality Pre-Coated Galvanized Steel Coils at Ex-Factory Price

Zhengde Color steel coil(PPGI),ppgi in our daily life, is called color coated coil or color coated steel plate. It is a chemical transfer process that makes the strip steel that is continuously degreased on the production line go through phosphating and other chemical transfer processes. Finally, the strip steel coated with organic paint is baked at high temperature to make products. Generally, the surface of this kind of steel plate has a relatively bright color. We also call this kind of steel plate and color steel plate and color steel plate. painted board.ppgi.

Location	category	value
Executive standard	National standard	GB/T12754-2019
	American Standard/European Standard	ASTM A792M
Cold rolled substrate	Width specification	Cold rolled substrate thickness		Including metallized layer, the thickness after painting		Label thickness
	1200mm	≥0.41mm		≥0.46mm		≥0.45mm
	Size deviation	Width tolerance		Upper deviation +4mm
				Lower deviation 0
		thickness		Upper deviation +0.05mm
				Lower deviation 0
	Yield Strength	>300MPA
	tensile strength	270-500MPA
	elongation after break	More than 20%
	Steel coil inner diameter	Standard: 508mm,Except for other agreements
metal coating	alloy composition	AlZnMg or galvanized AlMg
	Total Weight of Plating Both Sides (Outside/Inside)	150g/ (75/75 or 85/65)
	Neutral salt spray test	The surface of the board (without passivation, anti-fingerprint and other treatments on the surface) has a neutral salt spray test of more than or equal to 2500 hours, and there is no red rust on the surface.
		When the salt spray test on the wound surface (end surface) is greater than or equal to 1200, there is no red rust on the surface.
PPGI paint	PE coating structure standard (μm)	Paint structure	2/1		outside		≥25
					Inside		≥7
	pencil hardness	Not less than HB
	Specular Gloss of Topcoat	Glossiness of finish paint mirror surface: ≥40 degrees
	T bend value	2T
	Impact energy	Not less than 9J
	Neutral salt spray test	Greater than or equal to 1500h without bubbles
	UVB-313	greater than or equal to 700h
PPGI use environment	humidity	20% to 90%
	temperature	Min -45°C, Max 43°C
	unit ammonia	<30ppm
	unit carbon dioxide	<7000ppm
	unit oxygen	21%
	unit hydrogen sulfide	<5ppm

Customized High Quality Pre-Coated Galvanized Steel Coils at Ex-Factory Price

Complete range
For the use of color steel coils, we have to choose different types of color steel coils to manufacture different PPGI. Speaking of this, I have to briefly introduce the types of color steel coils, which are divided into five categories. That is, home appliances, optical materials, decorative materials, building materials, and packaging. Among them, the production process of color steel coils for home appliances is the most delicate and perfect.

Good performance
Zhengde color coated steel plate refers to the coating product obtained by applying organic paint to the surface of thin steel plate. PPGI has good anti-corrosion and decorative properties, as well as the good formability and processing properties of organic polymers and steel plates.

5S management
Before PPGI production, each post cleans the surrounding environment, ground sanitation, equipment spot inspection and each roller surface that directly affects the surface quality of the product in the working area according to the "Workshop 5S Management System" to ensure personal safety. At the same time, prepare tools, auxiliary materials, raw materials, etc. within the specified time. Ensure that the ground in the work area is free from dust, water and oil, ensure that the equipment is in the best condition and that the materials are used correctly.

Strictly check
PPGI image defects, surface defects, trace defects, edge defects, gold plating defects, size defects, coating defects, uneven defects, contamination defects, coating uneven defects, process defects, coating surface defects, physical property defects.

Quality first: production and inspection in strict accordance with production standards;
Price advantage: discounts based on real market prices;
Transaction security: There will be no loss of customer funds;
After-sales guarantee: the customer's problem is our problem;
Long-term cooperation: quality assurance, price advantage, sincere service can last for a long time.

Customized High Quality Pre-Coated Galvanized Steel Coils at Ex-Factory Price

Customized High Quality Pre-Coated Galvanized Steel Coils at Ex-Factory Price Shandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Africa, Oceania, Middle East, and Southeast Asia.
Customized High Quality Pre-Coated Galvanized Steel Coils at Ex-Factory Price

Customized High Quality Pre-Coated Galvanized Steel Coils at Ex-Factory Price
